Bicycle rack Slide

Options

• Construction

  • carbon steel (s235Jr)
  • stainless steel (Aisi 304)

• Mounting method

  • to be grouted in
  • to screw

Description

The Slide Bicycle Rack, product number 05.023, offers both functionality and style as an essential component of urban street furniture. Constructed with a choice of either robust carbon steel (S235JR) or premium stainless steel (AISI 304), it guarantees durability and resistance to the elements, making it suitable for a variety of settings. This rack features a sleek design with dimensions of 39 ¾ inches in width, 2 ¼ inches in depth, and stands 35 ½ inches above the ground. For installation, the total height reaches 47 ¼ inches when the anchor section is included.

Available in two installation options – to be grouted in or to screw – it provides flexibility depending on the urban environment and installation preferences. The weight varies slightly with the mounting method; the 'to be grouted in' model weighs 29 pounds, while the 'to screw' model is slightly lighter at 24 pounds. Designed to efficiently support a single bicycle, the Slide Bicycle Rack integrates seamlessly into any streetscape, offering cyclists a secure and stable place to park their bikes. This unit not only serves a practical function but also enhances the aesthetic of its surroundings, promoting a cyclist-friendly environment.

Specification

• Dimensions

  • width: 39 ³/₄ in
  • depth: 2 ¹/₄ in
  • height from ground surface: 35 ¹/₂ in
  • height with anchor section: 47 ¹/₄ in

• Weight

  • to be grouted in: 29 lb
  • to screw: 24 lb

• Materials

  • stainless or carbon steel

Files

• Product card
• Technical documentation
